Specification | |||
Screen | |||
Panel type | TFT LCD | Panel Size | 32-85 inch size |
Aspect Ratio | 16:09 | ||
Brightness | 500cd/m² | ||
Contract Ratio | 1400:01 | ||
Resolution Ratio | 1920*1080/3840x2160 choose | ||
Back light | WLED backlight | ||
Visual Angle | Horizontal 178/Vertical178 | ||
Pixel Pitch | 0.630x0.630mm(HxV) | ||
Color Components | 16.7M | ||
Response Time | 6ms | ||
Power Supply | Input:AC110-220V-50/60Hz | ||
Life of Panel | 60000Hours | ||
Speaker | 2*5W | ||
Material | Metal case SPCC+Tempered Glass | ||
Color | Black/Sliver/Customize | ||
Power Supply | AC100-240V,50/60Hz | ||
Max power consumption | ≤220W | ||
Operation Temperature | 0℃~50℃ | ||
Storage Temperature | -20℃~60℃ | ||
Android | |||
CPU | RK3568,Quad core ARM-A55,2.0GHz Optional | ||
GPU | Mali-G52 | ||
Memory | DDR 4GB(8/16G Optional) | ||
Built-in memory | EMMC32G(16G/32G/64/128G Optional) | ||
operating system | Android 9.0/10.0/11.0/12.0 system Optional | ||
Decoding resolution | Top support 2160P | ||
Video format | support RM/RMVB,MKV,TS,FLV,AVI,VOB,MOV,WMV,MP4 and so on. | ||
Play mode | Support a variety of playback modes,such as loop,timing,playback,etc. | ||
Network support | Ethernet,WiFi,(BT optional) | ||
RTC | support | ||
Time switch | support | ||
System upgrade | Support network upgrade,USB/TF card upgrade,computer upgrade | ||
Hardware interface | |||
DC | 12V/DC Input | ||
HDTV | HDTV2.0 Top support 4K@60HZ output | ||
LVDS | Dual 8-bit LVDS+backlight interface,up to 1920X1080 output | ||
EDP | EDP supports up to 1920X1080 output | ||
Memory Card | TF Memory Card | ||
USB | 6/5 HOST USB,1OTG USB | ||
Pin | 3/2 TTL serial ports,1 debug serial port | ||
IIC | 1,IIC interface(3.3 V) | ||
10 | 4,IO interface (3.3 V) | ||
Remote and lights | 1*remote,1*red light,1*green light | ||
Ethernet | 10M/100M Adaptive Ethernet | ||
Wireless | Wifi-2.4 g support (extensible BT-4.0) | ||
Trumpets | Support for horn interface,maximum support for two 825W horn output | ||
Audio | Support for left and right channels,MIC interface |
Revolutionize Your Display Experience with Gemdragon's Ultra-Thin Vertical Digital Signage
Unleash the Power of Modern Display – Learn More about Our Ultra-Thin Vertical Digital Signages and Elevate Your Space Now!
Specification
Support OEM / ODM
Infrared Touch ( optional )
32 / 43 / 49 / 55 / 65 / 75 / 86 inch Screen can support
Stand-alone / Android / windows version optional
black , gold , silver ( optional )
Gemdragon brings you the future of display technology with our Ultra-Thin Vertical Digital Signage. Designed to seamlessly blend into any environment, our digital signage is a perfect match for those who value both aesthetics and functionality. Its ultra-thin profile not only saves space but also adds a touch of modern sophistication to your business.
Our digital signage boasts a high-definition display that brings your content to life with stunning clarity and vibrant colors. The interactive touchscreen feature engages customers, providing them with an intuitive and engaging way to interact with your content. Whether it's retail advertising, public transport schedules, corporate presentations, or entertainment previews, our signage ensures your message is received loud and clear.
Retail: Transform how customers view your products. Display high-resolution images of your inventory, current promotions, and more.
Public Transit: Provide real-time updates, schedules, and notices in stations and terminals, improving the traveler's experience.
Corporate: Enhance your corporate environment with a sleek display of company information, news, or meeting details.
Entertainment and Dining: Showcase menus, upcoming events, or special offers in a visually appealing way.
Updating content on our Ultra-Thin Vertical Digital Signage is a breeze. Our user-friendly content management system allows you to easily upload and change display content, ensuring that your messages are always up-to-date and relevant.
Our commitment to sustainability is evident in our energy-efficient design, reducing operational costs while being environmentally friendly.
Discover how Gemdragon's Ultra-Thin Vertical Digital Signage can revolutionize the way you communicate with your audience. It's more than just a display; it's an experience. Visit us at [Our Product Page URL] to learn more and take the first step towards transforming your space today!
Gemdragon Display: Comprehensive Service at Every Step
Pre-sale service:
At Gemdragon, our relationship with clients begins long before a purchase is made. Our pre-sale services are designed to provide you with all the information and support needed to make an informed decision.
In-sale service:
During the purchase process, our commitment to excellence continues with an emphasis on quality, transparency, and communication.
After-sale service:
Our relationship with clients doesn't end at the point of sale. Our comprehensive post-sale services ensure continued satisfaction and support.
Dedicated Customer Service
At every step, our dedicated customer service team is here to assist you. Whether it’s a query about our products, assistance with an order, or support for an installed system, we are committed to providing prompt, professional service to ensure your complete satisfaction with Gemdragon Display.
Q1: What types of LCD digital signage solutions does Gemdragon offer?
A1: We offer a wide range of LCD digital signage solutions, including outdoor and indoor displays, interactive whiteboards, video walls, and custom digital signage tailored to specific industry needs.
Q2: Can Gemdragon provide customized digital signage solutions?
A2: Yes, we specialize in customized solutions. Our team works closely with clients to create signage that meets their specific requirements in terms of size, functionality, and design.
Q3: What warranty options are available for Gemdragon’s products?
A3: Alongside our standard two-year warranty, Gemdragon offers an extended warranty service, allowing customers to opt for up to a three-year warranty for their products. This extended warranty is part of our commitment to ensure long-term reliability and customer satisfaction.
Q4: How does Gemdragon ensure the quality of its products?
A4: Our products undergo rigorous quality control processes, including multiple tests and checks, to ensure high standards. We also hold various certifications, including CE, UL, RoHS, FCC, CB, ISO14001 and ISO9001.
Q5: What is the delivery timeline for Gemdragon’s products?
A5: Delivery times vary based on order size and customization requirements, but we generally ship within 3-8 working days after order confirmation. For bulk orders, timelines are discussed and agreed upon with the client.
Q6: Can you describe the shipping and delivery options offered by Gemdragon?
A6: Gemdragon offers a range of shipping options including sea, air, and land freight for international orders. Additionally, customers have the flexibility to arrange direct pickup or to have their orders sent to a chosen freight agent. Notably, for orders destined for the United States, we provide expedited 3-7 day door-to-door delivery services from our FBA overseas warehouse. Plans are underway to expand our overseas warehouse network to more countries.
Q7: Can I have my brand logo on the products?
A7: Absolutely! We offer branding options including custom logos on our products. This service might incur an additional fee depending on the complexity of the design.
Q8: How does the installation process work for Gemdragon’s digital signage?
A8: We provide comprehensive installation guidelines with our products. Additionally, we offer remote assistance and, for larger projects, on-site installation services can be arranged.
Q9: What kind of technical support does Gemdragon offer?
A9: We offer technical support via email, phone, and video conferencing. Our skilled technicians are available to assist with any queries or issues that may arise.
Q10: What payment methods does Gemdragon accept?
A10: We accept various payment methods including bank transfers, credit cards, and online payment platforms. Payment terms can be discussed and tailored to suit client needs.
Q11: How can I get a quote for a specific product or solution?
A11: For quotes, please contact us directly through our website, email, or phone. Our sales team will assist you with detailed information and pricing based on your requirements.
